La table ci-dessous représente, pour les 3 Subsets de caractères du Code
128, la composition barre (B), espace
(E) de chaque caractère
ASCII dont l'épaisseur
est de 1, 2, 3 ou 4 :
Caractère N° |
Subset A |
Subset B |
Subset C |
Composition B E B E B E |
---|---|---|---|---|
0 | SP | SP | 00 | 2 1 2 2 2 2 |
1 | ! | ! | 01 | 2 2 2 1 2 2 |
2 | " | " | 02 | 2 2 2 2 2 1 |
3 | # | # | 03 | 1 2 1 2 2 3 |
4 | $ | $ | 04 | 1 2 1 3 2 2 |
5 | % | % | 05 | 1 3 1 2 2 2 |
6 | & | & | 06 | 1 2 2 2 1 3 |
7 | ' | ' | 07 | 1 2 2 3 1 2 |
8 | ( | ( | 08 | 1 3 2 2 1 2 |
9 | ) | ) | 09 | 2 2 1 2 1 3 |
10 | * | * | 10 | 2 2 1 3 1 2 |
11 | + | + | 11 | 2 3 1 2 1 2 |
12 | , | , | 12 | 1 1 2 2 3 2 |
13 | - | - | 13 | 1 2 2 1 3 2 |
14 | . | . | 14 | 1 2 2 2 3 1 |
15 | / | / | 15 | 1 1 3 2 2 2 |
16 | 0 | 0 | 16 | 1 2 3 1 2 2 |
17 | 1 | 1 | 17 | 1 2 3 2 2 1 |
18 | 2 | 2 | 18 | 2 2 3 2 1 1 |
19 | 3 | 3 | 19 | 2 2 1 1 3 2 |
Caractère N° |
Subset A |
Subset B |
Subset C |
Composition B E B E B E |
20 | 4 | 4 | 20 | 2 2 1 2 3 1 |
21 | 5 | 5 | 21 | 2 1 3 2 1 2 |
22 | 6 | 6 | 22 | 2 2 3 1 1 2 |
23 | 7 | 7 | 23 | 3 1 2 1 3 1 |
24 | 8 | 8 | 24 | 3 1 1 2 2 2 |
25 | 9 | 9 | 25 | 3 2 1 1 2 2 |
26 | : | : | 26 | 3 2 1 2 2 1 |
27 | ; | ; | 27 | 3 1 2 2 1 2 |
28 | < | < | 28 | 3 2 2 1 1 2 |
29 | = | = | 29 | 3 2 2 2 1 1 |
30 | > | > | 30 | 2 1 2 1 2 3 |
31 | ? | ? | 31 | 2 1 2 3 2 1 |
32 | @ | @ | 32 | 2 3 2 1 2 1 |
33 | A | A | 33 | 1 1 1 3 2 3 |
34 | B | B | 34 | 1 3 1 1 2 3 |
35 | C | C | 35 | 1 3 1 3 2 1 |
36 | D | D | 36 | 1 1 2 3 1 3 |
37 | E | E | 37 | 1 3 2 1 1 3 |
38 | F | F | 38 | 1 3 2 3 1 1 |
39 | G | G | 39 | 2 1 1 3 1 3 |
Caractère N° |
Subset A |
Subset B |
Subset C |
Composition B E B E B E |
40 | H | H | 40 | 2 3 1 1 1 3 |
41 | I | I | 41 | 2 3 1 3 1 1 |
42 | J | J | 42 | 1 1 2 1 3 3 |
43 | K | K | 43 | 1 1 2 3 3 1 |
44 | L | L | 44 | 1 3 2 1 3 1 |
45 | M | M | 45 | 1 1 3 1 2 3 |
46 | N | N | 46 | 1 1 3 3 2 1 |
47 | O | O | 47 | 1 3 3 1 2 1 |
48 | P | P | 48 | 3 1 3 1 2 1 |
49 | Q | Q | 49 | 2 1 1 3 3 1 |
50 | R | R | 50 | 2 3 1 1 3 1 |
51 | S | S | 51 | 2 1 3 1 1 3 |
52 | T | T | 52 | 2 1 3 3 1 1 |
53 | U | U | 53 | 2 1 3 1 3 1 |
54 | V | V | 54 | 3 1 1 1 2 3 |
55 | W | W | 55 | 3 1 1 3 2 1 |
56 | X | X | 56 | 3 3 1 1 2 1 |
57 | Y | Y | 57 | 3 1 2 1 1 3 |
58 | Z | Z | 58 | 3 1 2 3 1 1 |
59 | [ | [ | 59 | 3 3 2 1 1 1 |
Caractère N° |
Subset A |
Subset B |
Subset C |
Composition B E B E B E |
60 | \ | \ | 60 | 3 1 4 1 1 1 |
61 | ] | ] | 61 | 2 2 1 4 1 1 |
62 | ^ | ^ | 62 | 4 3 1 1 1 1 |
63 | _ | _ | 63 | 1 1 1 2 2 4 |
64 | NUL | ' | 64 | 1 1 1 4 2 2 |
65 | SOH | a | 65 | 1 2 1 1 2 4 |
66 | STX | b | 66 | 1 2 1 4 2 1 |
67 | ETX | c | 67 | 1 4 1 1 2 2 |
68 | EOT | d | 68 | 1 4 1 2 2 1 |
69 | ENQ | e | 69 | 1 1 2 2 1 4 |
70 | ACK | f | 70 | 1 1 2 4 1 2 |
71 | BEL | g | 61 | 1 2 2 1 1 4 |
72 | BS | h | 72 | 1 2 2 4 1 1 |
73 | HT | i | 73 | 1 4 2 1 1 2 |
74 | LF | j | 74 | 1 4 2 2 1 1 |
75 | VT | k | 75 | 2 4 1 2 1 1 |
76 | FF | l | 76 | 2 2 1 1 1 4 |
77 | CR | m | 77 | 4 1 3 1 1 1 |
78 | SO | n | 78 | 2 4 1 1 1 2 |
79 | SI | o | 79 | 1 3 4 1 1 1 |
Caractère N° |
Subset A |
Subset B |
Subset C |
Composition B E B E B E |
80 | DLE | p | 80 | 1 1 1 2 4 2 |
81 | DC1 | q | 81 | 1 2 1 1 4 2 |
82 | DC2 | r | 82 | 1 2 1 2 4 1 |
83 | DC3 | s | 83 | 1 1 4 2 1 2 |
84 | DC4 | t | 84 | 1 2 4 1 1 2 |
85 | NAK | u | 85 | 1 2 4 2 1 1 |
86 | SYN | v | 86 | 4 1 1 2 1 2 |
87 | ETB | w | 87 | 4 2 1 1 1 2 |
88 | CAN | x | 88 | 4 2 1 2 1 1 |
89 | EM | y | 89 | 2 1 2 1 4 1 |
90 | SUB | z | 90 | 2 1 4 1 2 1 |
91 | ESC | { | 91 | 4 1 2 1 2 1 |
92 | FS | | | 92 | 1 1 1 1 4 3 |
93 | GS | } | 93 | 1 1 1 3 4 1 |
94 | RS | ~ | 94 | 1 3 1 1 4 1 |
95 (Hex 7F) | US | DEL | 95 | 1 1 4 1 1 3 |
96 (Hex 80) | FNC 3 | FNC 3 | 96 | 1 1 4 3 1 1 |
97 (Hex 81) | FNC 2 | FNC 2 | 97 | 4 1 1 1 1 3 |
98 (Hex 82) | SHIFT | SHIFT | 98 | 4 1 1 3 1 1 |
99 (Hex 83) | Subset C | Subset C | 99 | 1 1 3 1 4 1 |
100 (Hex 84) | Subset B | FNC 4 | Subset B | 1 1 4 1 3 1 |
101 (Hex 85) | FNC 4 | Subset A | Subset A | 3 1 1 1 4 1 |
102 (Hex 86) | FNC 1 | FNC 1 | FNC 1 | 4 1 1 1 3 1 |
Caractère N° |
Start Code | Composition B E B E B E |
---|---|---|
103 (Hex 87) | START (Subset A) | 2 1 1 4 1 2 |
104 (Hex 88) | START (Subset B) | 2 1 1 2 1 4 |
105 (Hex 89) | START (Subset C) | 2 1 1 2 3 2 |
Caractère N° |
Stop Code | Composition B E B E B E B |
---|---|---|
106 | STOP | 2 3 3 1 1 1 2 |
